LoRaWan Gateway
IP67
Specifications
GNSS
GPS, GLONASS, QZSS, SBAS
Size
240 x 164 x 90.9 mm
Power
802.3af PoE or 6–12V DC via M12 Connector
Memory
512 MB DDR4 RAM, 8 GB eMMC
Weight
1463g
Antenna
2 x 50Ω N-Female External LoRaWAN Antenna Connectors
TX Power
Max. 27 dBm
Processor
Quad-Core 1.5 GHz ARM Cortex-A53
VPN Support
OpenVPN, IPsec, PPTP, L2TP, GRE, DMVPN, WireGuard
Installation
Wall or Pole Mounting
RX Sensitivity
-140 dBm @292 bps
LoRaWAN Channels
8 (Half/Full-Duplex)
LoRaWAN Frequency
CN470, IN865, EU868, RU864, US915, AU915, KR920, AS923-1/2/3/4
Power Consumption
Typical 3.6W, Max. 4.8W
Supported Devices
Around 2000 LoRaWAN Class A/B/C Devices
Ingress Protection
IP67
Operating Humidity
0–95% RH (Non-condensing)
Transmission Range
Up to 15 km (Line of Sight)
Network Integration
MQTT(S), HTTP(S), BACnet/IP, BACnet/SC, Modbus TCP, Modbus RTU over TCP
Backhaul Connectivity
Ethernet (RJ45 10/100/1000 Mbps), Wi-Fi 2.4 GHz, and 4G LTE
Operating Temperature
-40°C to +70°C
Multifunctional Button
Reset Button
